Switchcraft

TTPH96K1NO

1RU, 2X48 TT/Bantam w/4' Harness To IDC Panel - Normals Brought Out

Out of stock
This item is special order


Buy Now

View More From This Family

Configuration

  • Number of Conductors: 3
  • Termination Style: IDC
  • Contact Plating: Gold
  • Color: Black
  • Packaging Type: Box
  • Number of Stations: 96
  • Rack Spaces: 1
  • Standard Connector Type: TT/Bantam Jacks & Plugs
  • Normalling: Full
  • Special Feature: 4' Wire Harness
  • Wired: 1
  • Front Connector: TT/Bantam
  • Jack Layout: 2x48

Electrical

  • Contact Resistance: 0.03 Ohms
  • Dielectric Withstanding Voltage: 500 Volts
  • Insulation Resistance: 10000 MOhms
  • Voltage Rating: 140 Volts
  • Current Rating: 0.1 Amps

Mechanical

  • Life Cycle: 30000 Cycles
  • Operating Force: 7 lbs

Environmental

  • Maxiumum Temperature: 50 C

Compliance

  • RoHS Compliant: Compliant
  • REACH Compliant: Compliant
  • Brand: Switchcraft

Material

  • Contact Material: Gold Alloy
  • Spring Material: Copper Alloy
