Switchcraft

TS2P6F26

Dura-Twist Threaded Locking Connector, Panel Mount, 6 position, Female

In stock
Drawings:


Buy Now

View More From This Family

Configuration

  • Number of Conductors: 6
  • Product Line: Dura-Twist
  • Mounting Type: Panel
  • Mounting Feature: Front Mount
  • Gender: Female
  • Contact Size: 26 AWG
  • Termination Style: Solder/Crimp
  • Contact Plating: Gold
  • Epoxy: Without Epoxy
  • Color: Nickel
  • Locking: Locking
  • Sealed: Sealed
  • Insert Material: Medical Technology LCP
  • Packaging Type: Bulk

Electrical

  • Contact Resistance: 0.01 Ohms
  • Insulation Resistance: 100000 MOhms
  • Voltage Rating: 30 Volts
  • Current Rating: 2.5 Amps

Mechanical

  • Life Cycle: 5000 Cycles
  • Operating Force: 10 lbs
  • Coupling Locking Style: Threaded
  • Mounting Torque: 40 in-lbs

Environmental

  • Temperature Range: -40?C to +135?C
  • Shielding: Shielded
  • Flame Rating: UL94V-0
  • Moisture Resistance: MIL-STD-202G Method 106G
  • Salt Spray: MIL-STD-202G Method 101E Test Cond B
  • Vibration: Mil-Std 202G Method 201A
  • Minimum Temperature: -40 C
  • Maxiumum Temperature: 135 C

Compliance

  • RoHS Compliant: 1
  • CSA: 1
  • UL: 1
  • REACH Compliant: 1
  • Brand: Switchcraft
  • IP Rating: IP68
  • UV Rating: F1
  • Thermal Shock: Mil-Std 202G method 107G
  • IP65: 1
  • IP66: 1
  • IP67: 1
  • IP68: 1
  • IP69K: 1
  • Current Interruption: Not for Current Interruption

Dimensional

  • Outer Diameter: 0.5 in

Material

  • Body Material: Copper Alloy
  • Body Plating: Electroless Nickel
  • Contact Material: Copper Alloy
  • Contact Plating Type: Gold
  • Insert Material Type: Medical Technology LCP
  • O-Ring Material: Silicone
  • Hardware Material: Copper Alloy, Nickel Plated
